Building the doll
Companion to the doll. Technical detail lives here so the main page stays clean.
Two tiers, on purpose
Tier 1, the pilot (this summer).
Off-the-shelf recordable sound modules sewn into a locally made doll body. The kind of module used in greeting cards and teddy bears: record up to 30 seconds per module, press to play. Two or three modules give a doll a handful of phrases. No soldering, no firmware, under $40 all-in. The point is to put a real doll in a real child's hands fast and learn what matters.
| Tier 1 part | Price |
|---|---|
| Recordable sound modules with press activation, 2 or 3 | about $8 each |
| Doll body, sewn in community (fabric, stuffing, thread) | |
| Coin cells come with the modules; sewn-shut pouches keep them away from children | |
| Total: under $40, one evening of assembly | |
Tier 2, the real one.
A small microcontroller board with proper audio, loaded from the community's own recordings, built to be reloadable so the same doll design serves any Nation and any language.
| Tier 2 part (working list, prices approximate) | Price |
|---|---|
| Microcontroller with audio support (ESP32-S3 mini class) | $8 to $12 |
| I2S audio amplifier (MAX98357A class) | $6 |
| Small speaker, 4 ohm 3 watt | $4 |
| MicroSD card for audio files, 8 GB is overkill | $6 |
| Two soft buttons (squeeze sensors in the hands) | $4 |
| AA battery holder with screwed, child-safe compartment. AA over lithium on purpose: toy safety first. | $5 |
| Power switch, wiring, washable inner pouch for the electronics | $8 |
| Board + speaker + battery estimated total: $40 to $55 per doll at single quantities, meaningfully less at batch quantity | |
Behavior: squeeze a hand, the doll speaks Anishinaabemowin. Squeeze again within a few seconds, it repeats in English. A switch inside the pouch selects Anishinaabemowin-only mode for immersion households. Audio is plain WAV files on the card: no app, no pairing, no account, and a parent or a language teacher can change the phrase set by swapping files.
Safety, treated as a feature
Toys for under-threes carry real obligations: no small detachable parts, sewn-in electronics pouch, screwed battery compartment, volume capped, washable outer body with the pouch removed. Canada Consumer Product Safety Act and the toy regulations apply to anything distributed, even gifts; the small-batch stage includes getting this checked properly rather than guessed at.
Open hardware, like the rest of the project
The Tier 2 design (board choice, wiring, enclosure pattern, firmware) will be published openly, the same posture as the project's code: any Nation can build the doll and load their own language. The voices themselves are never published; each community holds its own.
